CUZ purlin machine de - coiler with punching, economic design for heavy gauge purlin machine

Quick Detail:

1. Thickness : 1.6-3.0mm
2. Material : Galvanized Steel, G345
3. Input width : < 600mm
4. Material weight : 5MT
5. Coil inner diameter : 470-510mm

Description/Technical Parameter details of the de-coiler

Un-powered; Load capacity= MAX.5Ton

Hydraulic system to expand coil inner hole, Pump motor: 3KW

Coil inner–diameter=510+/-30mm

Coil Width= MAX.600mm

Mandrel rotation: Draft type

Features:

Drag by roll former

Hydraulic group to expand or loose

Suit with 15mpm roll former

Application:

Manual un-coiler is always supplied to work with heavy-duty roll forming machines such as C/U/Z/L or Sigma or Omega profile machine or heavy-duty metal sheet embossing machine lines (sometimes customers may require a hydraulic un-coiler for regular roll forming machines as well,

Profile Drawing/Layout/Equipment reference pictures:
