Slotted Strut Channel Roll Forming Machine 10T 41 X 21 Tile, Solar Strut U Channel Forming Machine

Quick Detail:

1. Thickness : 1.5-2.5mm
2. Material : GI/PPGL
3. Input width: as per order
   1. Effective width:
   2. Material weight: 5MT cap.
   3. Coil inner diameter : 508mm
   4. Driven way: by driven motor
   5. Cutting way: by hydraulic power pack
   6. Cutting tolerance : ±1mm

Application:

There are many sizes and many regular holes for cable trays, so how to change the size and how to punch the holes is the main issue when the manufacturer design the machine

Nowadays, more and more adopt to un-coiler, independent pre-leveling device, servo feed in device, presser with different punching dies, roll former, stop to cut or flying cut device, no power run out rack or pneumatic stacker, PLC control systems as complete lines to improve the production speed largely

Machine list:

1. Un-coiler
2. Independent pre-leveling device
3. Professional lubrication device
4. Auto servo feed in device
5. Presser with different punching tools
6. Roll former
7. Stop to cut cutting device
8. No power Rack
9. Siemens brand PLC and touch screen, Schneider brand inverter
10.

Description/Technical Parameter details of complete line:

• 2 Tons Hydraulic Un-coiler with pre-leveling device

Motorized driving coil rotation, auto stop/start control, 2.2KW

Load capacity=2Ton

Coil width: 200mm

Coil Inner-diameter: Φ510±30mm

• Independent pre-leveling device

For heavy gauge material

Driven and level by motor

• Professional Lubrication device

Equipped between the roller feeder and the press

• Auto Feed in Device

Servo motor: YASKAWA, 1.8KW or as order

• Presser

Capacity: 80/110 tons or as per detailed requirement

Chinese Brand: YANGLI

• Roll Forming machine

18 stages to form

Rollers manufactured from Cr12, heat treatment

Shafts Diameter=ф75mm, Precision Machined

Main motor =11KW, Frequency speed control

Max. line speed of roll former:Approx. 12-15m/min

• Hydraulic cutting device

Flying cut

After cut off, there are 8mm material waste

• PLC Control System

Siemens brand PLC and touch screen, Schneider brand Inverter, Omron encoder

Profile Drawing/Layout/Equipment reference pictures:
