    Floor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high rib

    Ask Lasest Price
    Brand Name : NKH ROLL FORMING MC
    Model Number : TR153-290-870
    Price : negotiable
    Supply Ability : 5 sets/months
    Delivery Time : 60 working days
    Certification : CE
    • Product Details
    • Company Profile

    Floor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high rib

    Floor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high rib


    1. Description of floor tile making machine galvanized steel floor decking sheet roll forming machine

    Metal roofing decks are available in a variety of types including narrow rib, intermediate rib, wide rib, and deep rib, and are used to support insulation or lightweight concrete and the waterproof membrane of a roof.

    These metal roofing deck can be left exposed for open ceiling designs or manufactured with added acoustical perforations


    Our automatic deck panel machine consist of decoiler, control by PLC and encoder which cut automatically at required length. Easy to operate.


    We have various designs, coil width from 900-1250mm all have.


    2. Technical details of galvanized steel deck panel floor tile sheet metal forming machine


    Machine Specifications
    WeightAbout:38000kgs
    SizeAbout :20mx2.2mx1.3m(length x width x height)
    ColorMain color: blue and orange
    Warning color: yellow
    Suitable Raw Material
    MaterialGalvanized Steel Coils
    Thickness0.8-1.25mm
    Yield Strength235Mpa
    Main Technical Parameters
    Quantity of forming rollers stations38
    Diameter of forming rollers shafts895mm solidt
    Roll Forming Speed20m/min
    Forming rollers materialNo.45 steel, coated with chromed treatment
    Cutter materialCR12 mould steel, with quenched treatment
    Controlling systemPLC and Converter
    Electric Power requirementMain motor power: 2*18.5kw
    Hydraulic unit motor power: 7.5kw
    Electric voltageAccording to customer’s requirement

    3. Main components of roll forming machine


    Decoiler1 Set
    Guiding Equipment1 Set
    Roll Forming Unit1 Set
    Post Cutting Unit1 Set
    Hydraulic Station1 Set
    PLC Control System1 Set
    Reveiving Table1 Set
    Hydraulic pre cutting systemOptional

    4. Profile drawings

    Floor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high ribFloor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high ribFloor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high ribFloor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high ribFloor deck roll forming machine, metal deck, steel deck, roofing panel, floor support, high rib
